HOME > Products > light Duty Truck > Foton Aumark E

Foton Aumark E LHD 6T 3360

Product DescriptionAUMARKAumark is a medium & high end light-duty truck brand under Foton Motor group, the Chinese largest commercial vehicle supplier. Foton Motor has collection o
Transmission Type: Manual
Drive Wheel: 4*2
Product Type: Aumark E
Origin: China
Trademark: Foton
Condition: New
Load Capacity: 1-10t
Online inquiry
Description Warranty Info
Description

Product Description

Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Surpem Supply System-Top of Lines Assembled, Creating the World Leading Parts Supply System
Engine-Cummins
Transmission-ZF
Electronics-Bosch/Continental
Brake system-WABCO
Drive system-Exedy
Air conditioning system-Rothwell, etc.
Bring together the world's largest suppliers of auto parts to create the strongest super truck
Specification
Basic parameter
Basic parameter
Vehicle type
CargoTruck
Platform
Aumark E
Drive form
4×2
LHD/RHD
LHD
Dimension
Dimension
Wheelbase (mm)
3360
Chassis Dimensions (mm)

chassis5960×1940×2250
Cargobox inner Dimensions (mm)
4170×1960×400
Weight
Weight
GVW (kg)
6T
Cabin
Cab
Body type
Aumark E
Width(mm)
1880
Height
/
Number of people/number of seats
3
Engine
Engine
Brand
FOTON
Model
4F25TC7
Type of fuel
Diesel
Displacement (L)
2499
Max power(kw/hp/rpm)
116kw(158Ps)
Max torque(Nm/rpm)
400Nm
Emission
Euro III
Gearbox
Gearbox
Brand
ZF
Type
ZF5S408
Gear position
5 MT
Brake
Brake
Brake type
Air brake
Auxiliary brake
ABS(4S4M)
Suspension
Suspension
Suspension form
Front and rear steel plate spring suspension
Leaf spring number(front/rear)
3/5+2
Front/Rear axle
Front/Rear axle
Rated load of front axle(T)
2.4T
Rated load of rear axle(T)
4.5T
Gear ratio
4.33
Tyre
Tyre
Model
Tubeless tires (British)LL7.00R16-12
Quantity
6+1
Frame
Frame
Dimensions
180×65×4.5
Fuel tank
Fuel tank
Capacity (L)
120L
Material
Aluminum alloy
Additional configuration
Additional configuration
Multi-media
MP3
Product Description
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Super power-Foton Cummins efficient engine
ISF series 2.8-liter and 3.8-liter fully electronically controlled light diesel engines with a power range covering 107-168 horsepower
lWith the characteristic of strong power, reliable durability, compact structure, efficient economy, it can meet Euro III to Euro VI emission standards.
·Fuel consumption FOTON CUMMINS engine is low (long-distance working conditions 13.5L/urban working conditions 14.86L)
·Long maintenance interval (maintenance once every 20,000 kilometers)
·Low oil consumption (4.5L per oil change)
·Long warranty mileage (100,000 km warranty,500,000 km without overhaul)
·One million kilometers of fuel consumption and maintenance over 5 years can save up to 25,000 US dollars
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
High cargo transportation efficiency
High vehicle usage efficiency
Excellent fleet management efficiency
·Large container , light self-weight, High load
510L high-strength steel, standard hole design, strong load capacity, strong versatility, low self-weight
It has a load capacity of 10 to 15% higher than other brand
Extra-large container is upgraded, container volume  increased by 10%, and loading efficiency is higher.
·Strong power, faster, and more efficient
ZF manual transmission, gear shifting is quick and easy, power output is smooth and efficient, fuel-saving, reliable and easy to operate
The maximum speed of the standard load can reach 120km/h
lHigher top speeds can meet maximum demand for segmentation logistics in the pursuit of timeliness
·Higher attendance
Compared with the last generation model, the reliability increased by 50%.Durable B10 life increased by 60%(B10> 500,000 km)
·Rigorous product verification procedure
Adopting Mercedes-Benz product experiment and verification process, through the extreme environment such as plateau, cold and high temperature, etc., accumulated 1.6 million kilometers of reliability verification , and the German DEKRA rigorous test has been completed.
·Higher value output:Lower investment,Less fuel consumption,Lower cost
Product features, performance, quality and reliability are consistent with Japanese high class Light-duty Trucks, which is more cost-effective.
·Provide IOV interface for realizing the docking with local vehicle platforms
Better realize value enhancement in user distribution, fuel efficiency, maintenance, fleet management, etc.
·Product portfolio
Three vehicle body types, total weight coverage of 3.5-14T multiple product combinations
·Model selection
1 ton-level platform; ton-level wheelbase is available; cargo compartment volume can be changed according to customer requirements
·Special purpose vehicle selection
A wide variety of special purpose vehicles, widely used in different industries and different fields
High performance braking system
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Braking stability: The braking deviation of 80km/h emergency braking is <0.8m
Air pressure brake: large braking torque, short pedal stroke, reliable use,  more suitable for heavy load
Hydraulic brake:balance force of braking, comfortable and easy to operate
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Active Safety- Multiple Electronic Auxiliary Equipments
·ABS Anti-lock braking system/EBD electronic brake force distribution
Four-channel ABS+EBD ensures stability and steering controllability during emergency braking
·LDWS lane departure warning system
The driver can be assisted to reduce the risk of traffic accidents caused by the car deviating from the lane by means of alarm .
·ESC Electronic stability control program
Meanwhile, it has the functions of ASR wheel anti-skid system and ESC electronic stability program, which can help improve steering stability during driving.
·AEBS autonomous emergency braking system
Minimize the degree of damage caused by collisions for unavoidable dangers
Company Profile
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
ABOUT US
•Shandong Xiangnong Special Vehicles Co., Ltd.
•1. Company Overview
•We are a high-tech enterprise integrating R&D, production, sales and service of environmental sanitation vehicle equipment.
•Based in Jiaxiang County, Shandong Province (the hometown of Zengzi), we have complete qualifications, standardized production and strong supply capacity.
•2. R&D Strength
•Founded in 2002, starting with biogas digester equipment R&D
•Launched our first three-wheeled tank-type slag suction truck in 2011
•Independently developed more than 120 vehicle models
•Own 59 patents and 9 software copyrights
•Awarded as National High-Tech Enterprise
•3. Production & Qualifications
•Recognized as National Announcement Enterprise in 2016
•Possess 3C, Occupational Health Management System and Safety Management System certifications
•Stable annual production capacity for large-scale orders
•Full series of sanitation vehicles for urban and rural scenarios
•4. Product Range
•Main products include:
•Fecal suction trucks & sewage suction trucks
•Combined cleaning-sewage suction trucks
•Water sprinklers & garbage trucks
•Road sweepers & electric sanitation vehicles
•5. Corporate Philosophy
•We adhere to the principle:
•Survive by Quality, Develop by Reputation, Innovate through Technology, Build Brands with Service
•6. Global Market & Service
•Products exported to the Middle East, Africa, Southeast Asia and other regions
•Established complete overseas sales and after-sales service system
•Stable cooperation with customers from UAE, Madagascar and other countries
Committed to meeting international market demands with reliable quality
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Certifications
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Packaging & Shipping
Foton Aumark Mini Cargo Van 4*2 Diesel Truck 6 Ton Light Duty Truck
Delivery Time: 1 to 50 days after order confirmation.
