Foton Miler RHD 4.5T 2480

Product DescriptionThe model of GVW in the 4.5-6.5T, mainly meets the upgrade needs of urban and suburban high-efficiency logistics, with better quality, high-efficiency high-end L
Transmission Type: Manual
Drive Wheel: 4*2
Product Type: Miler
Origin: China
Trademark: Foton
Condition: New
Load Capacity: 1-10t
Online inquiry
Description Warranty Info
Description

Product Description

Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
The model of GVW in the 4.5-6.5T, mainly meets the upgrade needs of urban and suburban high-efficiency logistics, with better quality, high-efficiency high-end Light-duty Truck model
The model of GVW in the 7.0-14T, mainly meets the demand for special purpose vehicles for intercity efficient logistics and transportation, with high-quality, high-efficiency high-end Light-duty Truck model
Basic parameter
Basic parameter
Vehicle type
CargoTruck
Platform
Miler
Drive form
4×2
LHD/RHD
RHD
Dimension
Dimension
Wheelbase (mm)
2480
Chassis Dimensions (mm)
chassis:4905×1905×2130
Cargobox inner Dimensions (mm)
3070×1870×400
Weight
Weight
GVW (kg)
4.5T
Cabin
Cab
Body type
Miler
Width(mm)
1730
Height
/
Number of people/number of seats
3
Engine
Engine
Brand
FOTON
Model
4F25TC15
Type of fuel
Diesel
Displacement (L)
2499
Max power(kw/hp/rpm)
96kW(129Ps)
Max torque(Nm/rpm)
320N.m
Emission
Euro V
Gearbox
Gearbox
Brand
ZF
Type
ZF5S368
Gear position
5 MT
Brake
Brake
Brake type
Hydraulic brake
Auxiliary brake
ABS(4S4M)
Suspension
Suspension
Suspension form
Front and rear steel plate spring suspension
Leaf spring number(front/rear)
3/3+1
Front/Rear axle
Front/Rear axle
Rated load of front axle(T)
1.8T
Rated load of rear axle(T)
3.5T
Gear ratio
5.125
Tyre
Tyre
Model
Tubeless tires (metric)L205/75R17.5-14
Quantity
4+1
Frame
Frame
Dimensions
170×55×4
Fuel tank
Fuel tank
Capacity (L)
70L
Material
Plastic
Additional configuration
Additional configuration
Multi-media
MP3+Bluetooth
WHY CHOOSE  MILER
The FOTON Miler light truck is equipped with FOTON's independently developed high-efficiency engine, achieving a perfect match between the vehicle and its powertrain. With core advantages such as homologous technology, cost control, and convenient service, it provides you with a logistics vehicle that is stable in performance, economical and practical, and worry-free after-sales. It is an ideal choice for urban distribution and short-haul transportation.
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
Key Advantages:
Homologous Technology, Perfect Match: The engine and vehicle are uniformly developed by FOTON, ensuring strong system compatibility and more stable and reliable performance.
Economical and Cost-Effective: Independent R&D and production effectively control vehicle costs and subsequent maintenance expenses, offering higher cost performance.
Convenient Service, Sufficient Parts: Relying on FOTON's strong national service network, maintenance is convenient and fast, with sufficient parts supply.
Mature Power, Strong Adaptability: The engine features mature technology, optimized for Chinese road conditions and fuel quality, with strong adaptability and high uptime.
Quality Assurance, Trustworthy: Inheriting FOTON's brand quality, it has passed rigorous tests and market verification, escorting your business.
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
High cargo transportation efficiency
High vehicle usage efficiency
Excellent fleet management efficiency
·Large container , light self-weight, High load
510L high-strength steel, standard hole design, strong load capacity, strong versatility, low self-weight
It has a load capacity of 10 to 15% higher than other brand
Extra-large container is upgraded, container volume  increased by 10%, and loading efficiency is higher.
·Strong power, faster, and more efficient
ZF manual transmission, gear shifting is quick and easy, power output is smooth and efficient, fuel-saving, reliable and easy to operate
The maximum speed of the standard load can reach 120km/h
lHigher top speeds can meet maximum demand for segmentation logistics in the pursuit of timeliness
·Higher attendance
Compared with the last generation model, the reliability increased by 50%.Durable B10 life increased by 60%(B10> 500,000 km)
·Rigorous product verification procedure
Adopting Mercedes-Benz product experiment and verification process, through the extreme environment such as plateau, cold and high temperature, etc., accumulated 1.6 million kilometers of reliability verification , and the German DEKRA rigorous test has been completed.
·Higher value output:Lower investment,Less fuel consumption,Lower cost
Product features, performance, quality and reliability are consistent with Japanese high class Light-duty Trucks, which is more cost-effective.
·Provide IOV interface for realizing the docking with local vehicle platforms
Better realize value enhancement in user distribution, fuel efficiency, maintenance, fleet management, etc.
·Product portfolio
Three vehicle body types, total weight coverage of 3.5-14T multiple product combinations
·Model selection
1 ton-level platform; ton-level wheelbase is available; cargo compartment volume can be changed according to customer requirements
·Special purpose vehicle selection
A wide variety of special purpose vehicles, widely used in different industries and different fields
High performance braking system
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
Braking stability: The braking deviation of 80km/h emergency braking is <0.8m
Air pressure brake: large braking torque, short pedal stroke, reliable use,  more suitable for heavy load
Hydraulic brake:balance force of braking, comfortable and easy to operate
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
Active Safety- Multiple Electronic Auxiliary Equipments
·ABS Anti-lock braking system/EBD electronic brake force distribution
Four-channel ABS+EBD ensures stability and steering controllability during emergency braking
·LDWS lane departure warning system
The driver can be assisted to reduce the risk of traffic accidents caused by the car deviating from the lane by means of alarm .
·ESC Electronic stability control program
Meanwhile, it has the functions of ASR wheel anti-skid system and ESC electronic stability program, which can help improve steering stability during driving.
·AEBS autonomous emergency braking system
Minimize the degree of damage caused by collisions for unavoidable dangers
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
Foton 3-Seater Rhd Multi-Purpose Mini Cargo Light Duty Truck
